Mini Flowatch 2

Mini solenoid pump, reliable and silent for the condensate removal of air conditioners up to 10kW/36000BTU
Ref: DE05LC440

Mini Flowatch 2

Benefits

Very Silent

Very silent pump (20.2 dBA), suitable for an installation in any room.

IP64 Protection

Protected against water splashes dust.

Quick Connectors

Make installation and maintenance easier.

Clear Reservoir

Facilitates maintenance thanks to a quick visualization of the reservoir state.

Brass Outlet

More solid and reliable than plastic.

Accessories Included

All accessories required for installation

Contents

Condensate Pump

Pump – Reservoir with air-vent tube – Power / alarm cable – Reservoir stand – Double-side adhesive – Inlet tube – Suction tube 1.8m – 1 clamp

Specification

Flowrate Max:

15L/hr

Suction Head Max:

2m

Discharge Head:

10m

Electrical Power:

19W

Voltage:

220-240V 50/60Hz

Alarm:

NO-NC

Noise Level:

Sound Icon

Protection Rating:

IP64

Thermal Protection:

Yes

Operating Cycle:

100%

Power/Alarm Cable:

1.6m
Dimensions:

86x28x48mm / 75x36x38mm
